Secure and Efficient Containment Systems

Containment Systems

Custom-Designed Containment Systems for Optimal

Operational Security

Safeguard your commercial space with our top-tier containment systems. At Tier 5 Systems, we understand the importance of a secure environment, and our containment solutions are engineered to provide safety and stability for your operations.

Secure and Efficient Containment Systems for Your Critical Operations. Tier 5 Systems offers bespoke containment solutions tailored to safeguard your sensitive equipment and optimize space utilization. Our expertly designed systems ensure optimal environmental conditions, enhancing the reliability and longevity of your assets. Trust us to deliver superior containment solutions that meet the specific needs of your business in Vancouver and across BC.

Slide Title

Write your caption here

Button
Slide title

Write your caption here

Button

Case Study

The Challenge

Choosing the right containment solution is essential for optimizing efficiency and effectiveness. Hot aisle containment enables users to increase the return air temperature to 30°C and above, enhancing the free cooling potential of the cooling system. While cold aisle containment is equally efficient, raising the return air temperature to 30°C or higher may create discomfort for data center personnel.

What We Did

An important aspect of implementing hot or cold aisle containment in your data center involves establishing a designated space within a space. Compliance with fire codes necessitates that each enclosed area be equipped with fire detection and suppression systems. To address this requirement, a ceiling system can be employed that is designed to disengage and allow the existing fire detection and suppression mechanisms to operate effectively. Two prevalent technologies are commonly used for this purpose: some ceiling tiles are constructed from a material that contracts and drops at 135°F, while others utilize a thermal switch that, when activated, releases a magnetic system holding the ceiling tiles in place.

What We Achieved

The driving force behind aisle containment in data centers is efficiency. By implementing containment solutions instead of traditional cooling methods, you can reduce your cooling requirements by 50%. This translates to lower energy and equipment expenses, as you'll need less cooling power to achieve the same results.
